Unit 21
Mechanics
Class 12 Mathematics
Dynamics
Class 12 Mathematics – Dynamics Notes PDF
The exact Google Drive ID is not exposed by the current Nepal eNotes page output, so no Drive ID has been invented.
Open Original Nepal eNotes PDF SourceNEB / CDC Focus
This chapter develops dynamics through motion of a particle, Newton’s laws of motion, and projectile motion. The emphasis is on mathematical modeling and solving problems.
1. Motion of a Particle in a Straight Line
If displacement is s(t),
For constant acceleration:
2. Newton’s Laws of Motion
A body remains at rest or in uniform straight-line motion unless acted on by a resultant external force.
Resultant force equals the rate of change of momentum; for constant mass:
F=ma.Interaction forces between two bodies are equal in magnitude and opposite in direction.
3. Momentum and Impulse
For constant force over time interval Δt, J=FΔt.
4. Projectile Motion
A projectile is modeled as a particle moving under gravity alone after projection, neglecting air resistance.
If it is projected with speed u at angle θ:
Horizontal acceleration is zero; vertical acceleration is −g.
5. Equation of the Trajectory
Eliminating t:
This is a quadratic equation in x, so the trajectory is a parabola.
6. Time of Flight, Maximum Height and Range
When a projectile lands at the same level from which it is launched:
Maximum range for fixed u occurs at θ=45°, giving Rmax=u²/g.
7. Worked Examples
If s=t³−3t²+2t, then v=3t²−6t+2 and a=6t−6.
A particle is projected at 20 m/s at 30°. Taking g=9.8, T=2(20)(1/2)/9.8≈2.04 s.
8. Common Mistakes
Keep the sign of gravitational acceleration consistent.
Do not use same-level range/time formulae when launch and landing heights differ.
Resolve velocity, not acceleration, into initial horizontal/vertical components.
Use the net/resultant force in F=ma.
9. Important Exam Questions
- Find velocity and acceleration from a displacement function.
- Apply Newton’s second law to a particle.
- Derive the projectile trajectory equation.
- Derive time of flight, maximum height and range.
- Show that maximum range occurs at 45°.
- Solve projectile numericals.
