CSS and Website Styling
Introduction to CSS
CSS stands for:
Cascading Style Sheets
CSS is used to control the appearance and layout of HTML webpages.
HTML mainly defines the structure of a webpage, while CSS controls how that webpage looks.
CSS can be used to control:
- Colors
- Fonts
- Backgrounds
- Borders
- Spacing
- Width and Height
- Position
- Navigation Bars
- Shadows
- Gradients
- Responsive Layouts
Types of CSS
There are three common ways to apply CSS to an HTML document:
- Inline CSS
- Internal CSS
- External CSS
1. Inline CSS
Inline CSS is written directly inside an HTML element using the style attribute.
Syntax
<tag style="property: value;">
Content
</tag>
Example
<!DOCTYPE html>
<html>
<body>
<h1 style="color: blue;">
A Blue Heading
</h1>
<p style="color: red;">
A Red Paragraph
</p>
</body>
</html>
Advantages of Inline CSS
- Easy for small changes
- Applied directly to one element
- Useful for quick testing
Limitation of Inline CSS
It becomes difficult to manage when many elements or webpages require the same styling.
2. Internal CSS
Internal CSS is written inside a <style> element in the <head> section of an HTML document.
Example
<!DOCTYPE html>
<html>
<head>
<style>
body {
background-color: powderblue;
}
h1 {
color: blue;
}
p {
color: red;
}
</style>
</head>
<body>
<h1>This is a Heading</h1>
<p>This is a Paragraph.</p>
</body>
</html>
Advantages of Internal CSS
- Useful for styling a single webpage
- Keeps styles separate from most HTML content
- Allows several elements to share styles
3. External CSS
External CSS stores CSS rules in a separate .css file.
The external stylesheet is connected to an HTML page using the <link> element.
HTML File
<!DOCTYPE html>
<html>
<head>
<link
rel="stylesheet"
href="styles.css">
</head>
<body>
<h1>This is a Heading</h1>
<p>This is a Paragraph.</p>
</body>
</html>
styles.css
body {
background-color: powderblue;
}
h1 {
color: blue;
}
p {
color: red;
}
Advantages of External CSS
- One stylesheet can control many webpages.
- Easier to maintain.
- Reduces repeated CSS code.
- Useful for larger websites.
- Helps maintain consistent design.
Difference Between Inline, Internal and External CSS
| Inline CSS | Internal CSS | External CSS |
|---|---|---|
| Written inside an HTML element. | Written inside <style> in <head>. | Written in a separate .css file. |
| Affects a specific element. | Usually affects one webpage. | Can affect many webpages. |
Uses style="". | Uses <style>. | Uses <link>. |
| Good for small changes. | Good for a single page. | Best for multi-page websites. |
CSS Selector
A CSS selector is used to select one or more HTML elements that will receive CSS styles.
CSS can select elements using:
- ID
- Class
- Element Name
- Grouping
- Universal Selector
Types of CSS Selectors
The main selectors discussed in this chapter are:
- ID Selector
- Class Selector
- Element Selector
- Grouping Selector
- Universal Selector
1. ID Selector
The ID selector selects an HTML element using its id attribute.
An ID should normally be unique on a webpage.
The ID selector uses the # symbol.
HTML
<p id="intro">
Welcome to CSS.
</p>
CSS
#intro {
color: blue;
text-align: center;
}
2. Class Selector
A class selector selects elements having a particular class value.
The class selector begins with a period ..
Example
<!DOCTYPE html>
<html>
<head>
<style>
.center {
text-align: center;
color: red;
}
</style>
</head>
<body>
<h1 class="center">
Red and Center-Aligned Heading
</h1>
<p class="center">
Red and Center-Aligned Paragraph
</p>
</body>
</html>
3. Element Selector
An element selector, also called a tag selector, selects HTML elements by their tag name.
Example:
<!DOCTYPE html>
<html>
<head>
<style>
body {
background-color: red;
}
p {
text-align: center;
font-size: 20px;
color: blue;
}
</style>
</head>
<body>
<p>
Hello World! This is a paragraph.
</p>
</body>
</html>
4. Grouping Selector
The grouping selector applies the same CSS rules to multiple selectors.
Selectors are separated using commas.
Example:
h1,
h2,
p {
text-align: center;
color: red;
}
5. Universal Selector
The universal selector uses the * symbol.
It selects all elements.
Example:
* {
text-align: center;
color: blue;
}
CSS Background
CSS background properties control the background of HTML elements.
Important background properties include:
background-colorbackground-imagebackground-repeatbackground-attachmentbackground-position
Background Color
The background-color property sets the background color of an element.
Example
body {
background-color: lightblue;
}
Background Image
The background-image property sets an image as the background.
Example
body {
background-image: url("paper.gif");
}
Background Repeat
The background-repeat property controls whether a background image repeats.
Common values include:
repeatrepeat-xrepeat-yno-repeat
Example:
body {
background-image: url("gradient_bg.png");
background-repeat: no-repeat;
}
Background Attachment
The background-attachment property determines whether the background scrolls with the page.
Example:
body {
background-image: url("img_tree.png");
background-repeat: no-repeat;
background-position: right top;
background-attachment: fixed;
}
Common values:
scrollfixed
Background Position
The background-position property specifies the starting position of a background image.
Example:
body {
background-image: url("background.gif");
background-repeat: no-repeat;
background-position: center;
}
CSS Borders
CSS border properties control the border around an element.
Important properties include:
border-styleborder-widthborder-color
Border Style
The border-style property specifies the appearance of a border.
Examples include:
soliddotteddasheddoublenone
Example:
h1 {
border-style: dotted;
}
Border Width
The border-width property specifies the thickness of the border.
Example:
p {
border-style: solid;
border-width: 2px;
}
Other values include:
border-width: thin;
border-width: medium;
border-width: thick;
Border Color
The border-color property sets the color of a border.
Example:
p {
border-style: solid;
border-color: red;
}
The border style should normally be defined before the border can be clearly displayed.
Border Shorthand Property
Several border properties can be written together:
p {
border: 2px solid black;
}
This represents:
2px → Width
solid → Style
black → Color
CSS Margin
Margin creates space outside an element’s border.
Main margin properties are:
margin-topmargin-rightmargin-bottommargin-left
Margin Example
div {
border: 1px solid black;
margin-top: 100px;
margin-right: 150px;
margin-bottom: 100px;
margin-left: 80px;
background-color: lightblue;
}
Margin Values
Margins can use values such as:
auto- Pixels
- Percentage
- Other CSS length units
Example:
div {
margin: auto;
}
Margin Shorthand
div {
margin: 20px;
}
This applies 20px margin to all sides.
Example:
div {
margin: 10px 20px;
}
This means:
Top & Bottom → 10px
Left & Right → 20px
CSS Padding
Padding creates space between the content and the border of an element.
The main padding properties are:
padding-toppadding-rightpadding-bottompadding-left
Padding Example
div {
border: 1px solid black;
background-color: lightblue;
padding-top: 50px;
padding-right: 30px;
padding-bottom: 50px;
padding-left: 80px;
}
Difference Between Margin and Padding
| Margin | Padding |
|---|---|
| Space outside the border. | Space inside the border. |
| Separates an element from other elements. | Separates content from the element border. |
Uses margin. | Uses padding. |
CSS Text Formatting
CSS provides many properties for controlling text.
Important properties include:
colortext-decorationtext-transformtext-shadowtext-alignletter-spacingline-heighttext-indentwhite-spaceword-spacing
Text Color
The color property sets the color of text.
Example:
h1 {
color: blue;
}
p {
color: green;
}
Text Decoration
The text-decoration property adds or removes text decoration.
Examples:
h1 {
text-decoration: overline;
}
h2 {
text-decoration: line-through;
}
a {
text-decoration: none;
}
Text Transform
The text-transform property controls capitalization.
Common values:
uppercaselowercasecapitalize
Example:
.uppercase {
text-transform: uppercase;
}
.lowercase {
text-transform: lowercase;
}
.capitalize {
text-transform: capitalize;
}
Text Shadow
The text-shadow property adds a shadow to text.
Example:
h1 {
text-shadow: 2px 3px;
}
A shadow color can also be added:
h1 {
text-shadow: 2px 2px 4px gray;
}
Text Alignment
The text-align property controls horizontal text alignment.
Values include:
leftrightcenterjustify
Example:
h1 {
text-align: center;
}
h2 {
text-align: left;
}
h3 {
text-align: right;
}
CSS Text Spacing
Important text-spacing properties include:
| Property | Purpose |
|---|---|
letter-spacing | Space between characters |
line-height | Space between lines |
text-indent | Indentation of first line |
white-space | Controls whitespace handling |
word-spacing | Space between words |
Letter Spacing
h2 {
letter-spacing: 5px;
}
h3 {
letter-spacing: -2px;
}
Line Height
The line-height property controls the vertical space between lines of text.
Example:
.small {
line-height: 0.7;
}
.big {
line-height: 1.8;
}
Text Indent
The text-indent property indents the first line of a text block.
Example:
p {
text-indent: 50px;
}
White Space
The white-space property determines how spaces and line breaks are handled.
Example:
p {
white-space: nowrap;
}
nowrap prevents the text from automatically wrapping to the next line.
Word Spacing
The word-spacing property changes spacing between words.
Example:
.one {
word-spacing: 10px;
}
.two {
word-spacing: -2px;
}
CSS Height and Width
The height and width properties control the dimensions of an element.
Example:
div {
height: 100px;
width: 500px;
background-color: powderblue;
}
Maximum Width
The max-width property limits the maximum width of an element.
Example:
div {
max-width: 800px;
}
This is useful when creating responsive layouts.
CSS Position
The position property controls how an element is positioned.
Common values include:
staticrelativeabsolutefixedsticky
Static Position
static is the default position.
.box {
position: static;
}
The element follows the normal document flow.
Relative Position
A relatively positioned element is moved relative to its original position.
.box {
position: relative;
top: 20px;
left: 20px;
}
Absolute Position
An absolutely positioned element is positioned relative to its nearest positioned ancestor.
.box {
position: absolute;
top: 50px;
left: 50px;
}
Fixed Position
A fixed element stays in the same position relative to the browser viewport even when the page scrolls.
.box {
position: fixed;
top: 10px;
right: 10px;
}
Sticky Position
A sticky element behaves like a relative element until it reaches a specified scroll position.
Example:
.navbar {
position: sticky;
top: 0;
}
CSS Float
The float property allows an element to move to the left or right, allowing surrounding content to wrap around it.
Common values include:
leftrightnoneinherit
Float Left
.left {
float: left;
}
Float Right
.right {
float: right;
}
Clear Property
The clear property controls whether an element can appear beside floated elements.
Example:
.clear {
clear: both;
}
CSS Overflow
The overflow property controls what happens when content is larger than an element’s defined box.
Common values include:
visiblehiddenscrollauto
Overflow: Visible
.box {
overflow: visible;
}
Content may extend outside the element.
Overflow: Hidden
.box {
overflow: hidden;
}
Content extending beyond the box is hidden.
Overflow: Scroll
.box {
overflow: scroll;
}
Scrollbars are provided.
Overflow: Auto
.box {
overflow: auto;
}
Scrollbars are displayed only when necessary.
Overflow X and Y
Horizontal and vertical overflow can be controlled separately.
.box {
overflow-x: auto;
overflow-y: hidden;
}
CSS Box Model
The CSS Box Model describes how every HTML element is represented as a rectangular box.
The box model contains four main parts:
- Content
- Padding
- Border
- Margin
Structure of CSS Box Model
Margin
┌─────────────────────────────┐
│ Border │
│ ┌─────────────────────────┐ │
│ │ Padding │ │
│ │ ┌─────────────────────┐ │ │
│ │ │ Content │ │ │
│ │ └─────────────────────┘ │ │
│ └─────────────────────────┘ │
└─────────────────────────────┘
Content
The content area contains:
- Text
- Images
- Other Elements
Its dimensions can be controlled using:
width:
height:
Padding
Padding creates space between the content and border.
Border
The border surrounds the content and padding.
Margin
Margin creates space outside the border.
Box Model Example
.box {
width: 200px;
height: 100px;
padding: 20px;
border: 5px solid black;
margin: 10px;
background-color: lightblue;
}
Total Width in Box Model
Using the default content-box sizing:
Total Width =
Width
+ Left Padding
+ Right Padding
+ Left Border
+ Right Border
+ Left Margin
+ Right Margin
Total Height
Total Height =
Height
+ Top Padding
+ Bottom Padding
+ Top Border
+ Bottom Border
+ Top Margin
+ Bottom Margin
CSS Navigation Bar
A navigation bar contains links that help users move between different parts of a website.
Common navigation bar types include:
- Horizontal Navigation Bar
- Navigation Bar with Dividers
- Fixed Navigation Bar
- Sticky Navigation Bar
- Dropdown Navigation Bar
Horizontal Navigation Bar
Example:
<!DOCTYPE html>
<html>
<head>
<style>
body {
font-family: Arial, sans-serif;
}
.navbar {
overflow: hidden;
background-color: #333;
}
.navbar a {
float: left;
display: block;
color: white;
text-align: center;
padding: 14px 20px;
text-decoration: none;
}
.navbar a:hover {
background-color: #ddd;
color: black;
}
</style>
</head>
<body>
<div class="navbar">
<a href="#home">Home</a>
<a href="#about">About</a>
<a href="#services">Services</a>
<a href="#contact">Contact</a>
</div>
</body>
</html>
Navigation Bar with Border Divider
A divider can be added between links.
.navbar a {
border-right: 1px solid #ddd;
}
.navbar a:last-child {
border-right: none;
}
Fixed Navigation Bar
A fixed navigation bar remains visible while the user scrolls.
.navbar {
position: fixed;
top: 0;
width: 100%;
}
Sticky Navigation Bar
A sticky navigation bar becomes fixed when it reaches a specified position.
.navbar {
position: sticky;
top: 0;
width: 100%;
}
Dropdown Navigation Bar
A dropdown menu displays additional links when users interact with a menu item.
Example:
<div class="navbar">
<a href="#home">
Home
</a>
<a href="#about">
About
</a>
<div class="dropdown">
<button class="dropbtn">
Services
</button>
<div class="dropdown-content">
<a href="#service1">
Service 1
</a>
<a href="#service2">
Service 2
</a>
<a href="#service3">
Service 3
</a>
</div>
</div>
</div>
CSS:
.dropdown {
float: left;
}
.dropdown-content {
display: none;
position: absolute;
background-color: #f9f9f9;
min-width: 160px;
box-shadow: 0 8px 16px rgba(0, 0, 0, 0.2);
}
.dropdown-content a {
display: block;
color: black;
padding: 12px 16px;
text-decoration: none;
}
.dropdown:hover .dropdown-content {
display: block;
}
Advanced CSS Properties
The source discusses several additional CSS properties, including:
- Rounded Corners
- Border Images
- Text Effects
- Gradients
- Shadows
CSS Rounded Corners
The border-radius property creates rounded corners.
Example:
.box {
border-radius: 25px;
background: #73AD21;
padding: 20px;
width: 200px;
height: 150px;
}
Rounded Border Example
.box {
border-radius: 25px;
border: 2px solid #73AD21;
padding: 20px;
}
CSS Border Image
The border-image property allows an image to be used as an element’s border.
Example:
.box {
border: 20px solid transparent;
border-image:
url("border.png")
30
round;
}
Important related properties include:
border-image-sourceborder-image-sliceborder-image-widthborder-image-outsetborder-image-repeat
CSS Text Effects
Important text-effect properties include:
text-overflowoverflow-wrapword-breakwriting-mode
Text Overflow
The text-overflow property controls how hidden overflowing text is shown.
Example using clipping:
.test1 {
white-space: nowrap;
width: 200px;
overflow: hidden;
text-overflow: clip;
}
Example using ellipsis:
.test2 {
white-space: nowrap;
width: 200px;
overflow: hidden;
text-overflow: ellipsis;
}
Word Wrapping
Long words can be wrapped onto a new line using:
p {
overflow-wrap: break-word;
}
The older word-wrap property name is also widely supported.
Word Breaking
The word-break property specifies line-breaking behaviour.
Examples:
.test1 {
word-break: keep-all;
}
.test2 {
word-break: break-all;
}
Writing Mode
The writing-mode property determines whether text flows horizontally or vertically.
Examples:
.horizontal {
writing-mode: horizontal-tb;
}
.vertical {
writing-mode: vertical-rl;
}
CSS Gradients
A gradient creates a smooth transition between two or more colors.
The source discusses:
- Linear Gradient
- Radial Gradient
Linear Gradient
A linear gradient changes colors along a straight line.
Syntax
background:
linear-gradient(
direction,
color1,
color2
);
Example
.box {
width: 300px;
height: 200px;
background:
linear-gradient(
to right,
red,
yellow
);
}
Linear Gradient with Angle
.box {
background:
linear-gradient(
45deg,
blue,
green
);
}
Linear Gradient with Multiple Colors
.box {
background:
linear-gradient(
to bottom,
red,
yellow,
green,
blue
);
}
Radial Gradient
A radial gradient spreads colors outward from a central point.
Example:
.box {
width: 300px;
height: 200px;
background:
radial-gradient(
circle,
red,
yellow
);
}
Radial Gradient with Position
.box {
background:
radial-gradient(
circle at left top,
blue,
green
);
}
Radial Gradient with Multiple Colors
.box {
background:
radial-gradient(
circle,
red,
yellow,
green,
blue
);
}
CSS Shadows
CSS supports shadows for text and boxes.
Text Shadow
h1 {
text-shadow: 2px 2px;
}
A more detailed example:
h1 {
text-shadow: 2px 2px 5px gray;
}
Box Shadow
The box-shadow property adds shadow around an element.
Example:
div {
box-shadow: 10px 10px;
}
Another example:
div {
box-shadow:
0 4px 12px
rgba(0, 0, 0, 0.25);
}
CSS Measurement Units
CSS measurement units define:
- Width
- Height
- Spacing
- Font Size
- Position
They can broadly be divided into:
- Absolute Units
- Relative Units
Absolute CSS Units
Examples include:
pxptcmmminpc
Pixels
.box {
width: 200px;
height: 100px;
}
px stands for pixels.
Points
p {
font-size: 12pt;
}
1pt is traditionally defined as 1/72 of an inch.
Centimetres
.box {
width: 5cm;
}
Millimetres
.box {
width: 50mm;
}
Inches
.box {
width: 2in;
}
Picas
.box {
width: 2pc;
}
One pica equals:
1pc = 12pt
Relative CSS Units
Important relative units include:
%emremvwvhvminvmaxchex
Percentage
.box {
width: 50%;
}
The value is relative to another relevant dimension, commonly the containing block.
em
em is relative to font size.
Example:
.box {
font-size: 2em;
}
rem
rem is relative to the font size of the root <html> element.
Example:
.box {
font-size: 1.5rem;
}
Viewport Width
vw represents a percentage of viewport width.
.box {
width: 50vw;
}
Viewport Height
vh represents a percentage of viewport height.
.box {
height: 50vh;
}
vmin
vmin is based on the smaller viewport dimension.
.box {
width: 50vmin;
}
vmax
vmax is based on the larger viewport dimension.
.box {
width: 50vmax;
}
ch
ch is approximately based on the width of the 0 character in the selected font.
Example:
.box {
width: 20ch;
}
ex
ex is based approximately on the x-height of the current font.
Example:
.box {
height: 5ex;
}
CSS Website Design
CSS can be used to create the basic layout of a website.
Common website sections include:
- Header
- Navigation Bar
- Main Content
- Footer
Website Header
A header is generally located at the top of a webpage.
It may contain:
- Logo
- Website Name
- Heading
- Introduction
Example:
.header {
background-color: #F1F1F1;
text-align: center;
padding: 20px;
}
Website Navigation Bar
A navigation bar provides links to important website pages.
Example:
.topnav {
overflow: hidden;
background-color: #333;
}
.topnav a {
float: left;
display: block;
color: #f2f2f2;
text-align: center;
padding: 14px 16px;
text-decoration: none;
}
.topnav a:hover {
background-color: #ddd;
color: black;
}
Website Content Layout
A webpage can use:
- One-Column Layout
- Two-Column Layout
- Three-Column Layout
One-column layouts are particularly useful on smaller screens.
Multi-column layouts can be used when more screen space is available.
Three-Column Layout
.column {
float: left;
width: 33.33%;
}
.row::after {
content: "";
display: table;
clear: both;
}
Responsive Layout
A responsive design adapts to smaller screens.
Example:
@media screen and (max-width: 600px) {
.column {
width: 100%;
}
}
This changes the columns into a vertically stacked layout on smaller screens.
Website Footer
The footer is placed near the bottom of a webpage.
It may contain:
- Copyright
- Contact Information
- Important Links
- Company Information
Example:
.footer {
background-color: #F1F1F1;
text-align: center;
padding: 10px;
}
Simple CSS Website Layout
<!DOCTYPE html>
<html>
<head>
<title>Simple Website</title>
<style>
body {
margin: 0;
font-family: Arial, sans-serif;
}
.header {
background-color: #f1f1f1;
padding: 20px;
text-align: center;
}
.topnav {
background-color: #333;
overflow: hidden;
}
.topnav a {
float: left;
color: white;
padding: 14px 16px;
text-decoration: none;
}
.topnav a:hover {
background-color: #ddd;
color: black;
}
.content {
padding: 20px;
}
.footer {
background-color: #f1f1f1;
text-align: center;
padding: 10px;
}
</style>
</head>
<body>
<div class="header">
<h1>My Website</h1>
</div>
<div class="topnav">
<a href="#">Home</a>
<a href="#">About</a>
<a href="#">Contact</a>
</div>
<div class="content">
<h2>Welcome</h2>
<p>
This is the main website content.
</p>
</div>
<div class="footer">
<p>
Copyright © My Website
</p>
</div>
</body>
</html>
Quick Revision
CSS
CSS stands for:
Cascading Style Sheets
It is used to style HTML webpages.
Types of CSS
- Inline CSS
- Internal CSS
- External CSS
CSS Selectors
- ID Selector
- Class Selector
- Element Selector
- Grouping Selector
- Universal Selector
ID Selector
#name {
color: red;
}
Class Selector
.name {
color: red;
}
Element Selector
p {
color: red;
}
Universal Selector
* {
margin: 0;
}
Background Properties
background-colorbackground-imagebackground-repeatbackground-attachmentbackground-position
Border Properties
border-styleborder-widthborder-color
Margin
Space outside a border.
margin: 20px;
Padding
Space inside a border.
padding: 20px;
Text Properties
colortext-aligntext-decorationtext-transformtext-shadowletter-spacingword-spacingline-height
Position Values
staticrelativeabsolutefixedsticky
Overflow Values
visiblehiddenscrollauto
CSS Box Model
Margin
↓
Border
↓
Padding
↓
Content
Rounded Corners
border-radius: 20px;
Text Shadow
text-shadow: 2px 2px 5px gray;
Box Shadow
box-shadow: 5px 5px 10px gray;
Linear Gradient
background:
linear-gradient(
to right,
red,
yellow
);
Radial Gradient
background:
radial-gradient(
circle,
red,
yellow
);
Common CSS Units
Absolute
pxptcmmminpc
Relative
%emremvwvhvminvmaxchex
Important Exam Points
- CSS stands for Cascading Style Sheets.
- CSS is used to style HTML webpages.
- CSS can be inline, internal, or external.
- Inline CSS uses the
styleattribute. - Internal CSS uses the
<style>element. - External CSS uses a separate
.cssfile. - The
<link>element connects external CSS to HTML. - CSS selectors select HTML elements for styling.
#represents an ID selector..represents a class selector.*represents the universal selector.- Grouping selectors are separated by commas.
background-colorchanges background color.background-imageadds a background image.background-repeatcontrols image repetition.background-positioncontrols background image position.border-stylecontrols border appearance.border-widthcontrols border thickness.border-colorcontrols border color.- Margin creates space outside the border.
- Padding creates space inside the border.
colorchanges text color.text-aligncontrols text alignment.text-transformchanges text capitalization.text-shadowcreates text shadow.letter-spacingcontrols spacing between letters.word-spacingcontrols spacing between words.line-heightcontrols spacing between text lines.widthandheightcontrol element dimensions.- CSS positioning includes static, relative, absolute, fixed, and sticky.
floatcan move an element to the left or right.overflowcontrols content that exceeds an element’s box.- The CSS Box Model contains content, padding, border, and margin.
- Navigation bars can be horizontal, fixed, sticky, or dropdown.
border-radiuscreates rounded corners.border-imagecan use an image as a border.text-overflow: ellipsiscan indicate clipped text.- CSS supports linear and radial gradients.
box-shadowcreates shadows around elements.- CSS uses both absolute and relative measurement units.
%,em,rem,vw, andvhare relative units.- Media queries can create responsive website layouts.
- A basic website layout may contain a header, navigation bar, content section, and footer.
Discussion
Share a helpful question, idea, or explanation with other students.
